I. Product Description
The XCMG Mobile Electrical Concrete Mixer Machine Central is a mobile electric concrete mixing equipment specially designed for flexible construction scenarios. It belongs to the core product line of XCMG Construction Machinery. The equipment adopts a modular design, integrating raw material storage, measurement, mixing, and discharging functions. The bottom is equipped with swivel tires and a towing device, allowing for short-distance relocation without the need for large lifting equipment. Compared to traditional fixed mixing stations, it is powered mainly by electricity, has low noise and zero emissions, and can work in conjunction with Self Loading Concrete Mixer and Self-Loading Concrete Mixer with pump, forming a complete concrete production - transportation chain, suitable for various construction scenarios. II. Technical Specifications
The rated mixing capacity of this mixing station is 2.5m³ per batch, with an hourly production efficiency of 10-15m³ of concrete, meeting the continuous supply requirements of small and medium-sized projects; raw material measurement accuracy: cement ±1%, sand and gravel ±2%, ensuring precise concrete mix ratio; a 11kW high-efficiency motor drives the mixing drum, with a mixing speed of 18r/min, and the homogeneity error of concrete ≤2%; the power supply mode supports dual modes of 380V industrial electricity and self-provided generator, and can switch to the generator for continuous operation in case of power failure; the total weight of the equipment is 8.5t, the minimum turning radius is 5.2m, suitable for narrow construction site relocation; the storage capacity: cement bin 50t, sand and gravel bin 100t, reducing the frequency of raw material replenishment.
III. Product Features and Advantages
Flexible and Easy Relocation: The modular design and towing-type mobile structure solve the problem of traditional fixed mixing stations being unable to move and having high relocation costs. Short-distance relocation can be directly towed, and long-distance disassembly transportation can be quickly assembled after long-distance transportation, with a 80% improvement in relocation efficiency compared to fixed mixing stations.
High Efficiency and Energy Saving: Compared to fuel-powered mixing stations, the electric drive reduces energy consumption by 30%, saving 8-10 yuan per cubic meter of concrete; and the noise is ≤75dB, suitable for construction scenarios with noise sensitivity such as residential areas and schools, and zero emissions comply with environmental protection requirements.
Strong Collaboration: As a product of XCMG Construction Machinery series, it can seamlessly receive raw materials from Self Loading Concrete Mixer, and can also be combined with self-loading concrete mixer with pump for concrete mixing and direct transportation, without the need for additional transfer equipment, reducing construction links.
IV. Application Scenarios
Urban Emergency Repair Projects: Used for road damage repair, pipeline laying, etc., the equipment can be quickly relocated and put into production within 1 hour, electric drive avoids fuel pollution, suitable for construction requirements in urban central areas, and with dual power supply modes, it can adapt to the unstable power supply in some rural areas, and with Self Loading Concrete Mixer, it can cover multiple construction points for raw material transportation.
Rural Infrastructure Projects: In rural roads and small bridge construction, the equipment can directly enter the construction site, without the need to build a fixed mixing station, dual power supply modes adapt to the unstable power supply in some rural areas, and with Self Loading Concrete Mixer, it can cover multiple construction points for raw material transportation.
Real Estate Supporting Construction: In the construction of residential area ancillary facilities (such as parking lots, landscape walkways), the equipment has a moderate size, can be relocated within the residential area, low noise and zero emissions avoid affecting residents' lives, and the production efficiency can match the scattered construction requirements, reducing concrete transportation losses. V. Customer Benefits
After using this mixing station, customers no longer need to invest in building a fixed mixing station, reducing the initial equipment investment cost; flexible relocation and dual power supply mode reduce construction restrictions, enabling quick response to different site demands; efficient energy-saving features lower long-term operating costs and reduce the risk of environmental penalties; the synergy with XCMG series equipment reduces equipment adaptation troubles and improves overall construction efficiency. Whether it's a municipal engineering team or a small construction company, they can achieve higher cost-effectiveness.
VI. Customer Reviews and Recommendations
"Previously, we used a fixed mixing station for municipal emergency repairs. The relocation took half a day. After switching to this XCMG mobile mixing station, it could be transported to the repair site in half an hour. The electric drive has low noise and there were no complaints from residents during construction in residential areas. It is particularly convenient when paired with the self-loading concrete mixer with pump." — Mr. Liu, the team leader of the municipal engineering team.
"For rural road construction, it is just right. There's no need to set up a mixing station. Electricity connection or generator use can be used for work. When combined with the Self Loading Concrete Mixer, it's very convenient to run back and forth between several construction sites, saving a lot of transportation costs compared to purchasing ready-mixed concrete." — Mr. Wang, the project leader of rural infrastructure construction.
"When conducting community construction, this equipment can be relocated flexibly in the community. It has low noise and no complaints from residents. The produced concrete is uniform in quality and no quality problems occurred later. It truly deserves to be a product of XCMG Construction Machinery." — Mr. Zhang, the director of real estate construction.
